TRANSFORMER (Single
Phase Cast Resin)
- Hasta 6kV,500 kVA
- Up to 6kV, 500 kVA
- Jusqu'a 6kV, 500 kVA
- Bis 6KV, 500 kVA
Technical
Characteristics
| Frequency |
50-60
Hz |
| Insulation |
Class
B-130�C |
| Windings |
Copper,
class HC-200�C |
| Test
voltage |
3
kV (1 min, 50 Hz) between input and output
3 kV (1 min, 50 Hz) between input and earth
0,5 kV (1 min, 50 Hz) between output and earth |
| Output
ripple |
TR
(without filter): 48%
TRF (with filter): 5% |
| Cover |
Cast
Resin |
| Protection
degree |
IP-20 |
| Ambient
temperature |
ta=
25�C |
| Standards |
IEC/EN/UNE-EN
61204 CE |
| Includes |
Fuse
in primary as from 300 W
DIN Rail mounting (TR 1,6 and TR 2,5) |
Dimensions
and Weights
Output
current
A(DC) |
Reference
(without capacitor filter) |
| TRA
(output 12 V DC) |
TRB
(output 24V DC) |
TRC
(output 48 V DC) |
| Dimensions
mm |
Weight
kg |
Dimensions
mm |
Weight
kg |
Dimensions
mm |
Weight
kg |
| A |
B |
C |
A |
B |
C |
A |
B |
C |
| 1,6 |
80 |
97 |
74 |
0,76 |
95 |
96 |
85 |
1,3 |
95 |
96 |
100 |
1,8 |
| 2,5 |
80 |
97 |
84 |
0,95 |
95 |
96 |
100 |
1,8 |
104 |
102 |
110 |
2,7 |
| 4 |
111 |
100 |
99 |
1,4 |
120 |
102 |
124 |
2,8 |
132 |
112 |
130 |
3,8 |
| 6,3 |
112 |
100 |
122 |
1,9 |
133 |
112 |
128 |
3,3 |
145 |
122 |
157 |
5,5 |
| 10 |
125 |
102 |
142 |
2,9 |
149 |
122 |
157 |
4,9 |
167 |
145 |
199 |
9,3 |
| 16 |
137 |
112 |
160 |
4,0 |
167 |
145 |
191 |
7,4 |
191 |
165 |
224 |
13,6 |
| 25 |
149 |
122 |
195 |
6,3 |
167 |
145 |
237 |
11,3 |
191 |
165 |
270 |
17,8 |
| 40 |
167 |
145 |
227 |
10,0 |
191 |
165 |
250 |
15,8 |
236 |
198 |
308 |
31,4 |
| 63 |
191 |
165 |
240 |
15,0 |
236 |
198 |
288 |
27,0 |
281 |
235 |
340 |
49,4 |
Output
current
A(DC) |
Reference
(with capacitor filter) |
| TRFA
(Output 12 V DC) |
TRFB
(Output 24V DC) |
TRFC
(Output 48 V DC) |
| Dimensions
mm |
Weight
kg |
Dimensions
mm |
Weight
kg |
Dimensions
mm |
Weight
kg |
| A |
B |
C |
A |
B |
C |
A |
B |
C |
| 1,6 |
133 |
97 |
84 |
1,1 |
148 |
96 |
85 |
1,5 |
157 |
102 |
110 |
2,9 |
| 2,5 |
148 |
96 |
99 |
1,5 |
148 |
96 |
100 |
2,0 |
169 |
112 |
106 |
3,5 |
| 4 |
164 |
96 |
122 |
2,0 |
173 |
102 |
124 |
3,0 |
197 |
122 |
149 |
5,8 |
| 6,3 |
174 |
102 |
142 |
3,0 |
186 |
112 |
138 |
4,1 |
216 |
145 |
169 |
7,7 |
| 10 |
190 |
112 |
150 |
3,7 |
202 |
122 |
167 |
6,0 |
220 |
145 |
209 |
11,2 |
| 16 |
202 |
122 |
185 |
5,4 |
220 |
145 |
211 |
9,9 |
244 |
165 |
234 |
16,1 |
| 25 |
250 |
250 |
205 |
8,6 |
270 |
280 |
225 |
15,0 |
290 |
310 |
265 |
27,7 |
|
